Mini RTP 1200 degree Tube Furnace with Halogen Tube Tube Furnace with Quartz Tube RTP Tube Furnace for Lab

Henan Chengyi Equipment Science and Technology Co.,Ltd

Category: Mechanical Parts & Fabrication Services

$1.00/--

Short Description

Mini RTP 1200 degree Tube Furnace with Halogen Tube Tube Furnace with Quartz Tube RTP Tube Furnace for Lab

CHENGYI Tube Furnace with Quartz Tube APPLICATION

1.Fast Annealing,Post-ion implantation annealing

2.RTO,RTN

3.Silicidation

4.Diffusion

5.Electrode alloying

6.Crystallization and densification

RTP Tube Furnace PARAMETERS

Product Name	Mini RTP Tube Furnace
Model	Mini-RTP
Furnace Type	Fast Heating/Cooling Sintering
Display Model	LED Digital Light
Maximum Temperature	1100?
Working Temperature	≤1000?
Heating rate	≤20?/Second
Heating zones	Single heating zone
Quartz Tube Diameter	O.D50*600mm
Inner Diameter	I.D 42*600mm
Heating Zone Length	100mm
Max Sample	35*25mm
Control mode	Intelligent PID auto control
Temperature Accuracy	±1?
Temperature curve	30 segments programmable
Over heat alarm	Have
Overcurrent protection	Have
Thermocouple Failure Protection	Have
Temperature Sensor	K-type thermocouple
Heating Element	3pieces Infrared tube
Quartz Tube Material	High Purity Quartz
After-sales service	12 month warranty, durable maintaince and repair support
Power Supply	220V 50HZ
Rated power	1.5kw
Overall dimensions	610×400×410 (mm )
Packing	3-ply wooden case
Accessories	Protective Glove,Crucible Tong,Crucible,Quartz Tube,Vacuum Flange,User Manual.

As a professional tube furnace exporter, we can supply high quality laboratory tube furnace with cheap price. For more industry information, view www.hnchengyi.com online today.
