RN Series Indoor Narrow Pixel Pitch Advertising LED Display exporter Advertising LED Display China
Pixel Pitch:1.667mm/1.875mm/1.923mm
Indoor LED Video Wall Features
High Definition Picture Quality, Perfect Visual Feast
The screen with brilliant display performance,
fast dynamic picture processing,
it can easily bring you the clear and vivid visual world.
Seamless splicing and fast installation
HD series features our innovative die-casting
aluminum housing and unique quick-lock design that
make seamless splicing and fast installation
Large viewing angle
Large viewing angle is up to 160°,which attract more audience from different directions
16:9 design as TV
LED cabinet is 16:9 design,which make every cabinet is also an
independent LED TV with 4096x2160 dots resolution.
Indoor Rental LED Display Specification
|
Model name
|
RN-P1.667
|
RN-P1.875
|
RN-P1.923
|
|
Pixel pitch
|
1.667mm
|
1.875mm
|
1.923mm
|
|
Module size
|
200mm*300mm
|
240mm*240mm
|
200mm*300mm
|
|
Resolution of module
|
120*180 dots
|
128*128 dots
|
104*156 dots
|
|
Density of pixel
|
360,000 dots/m2
|
280,000 dots/m2
|
270,400 dots/m2
|
|
LED Packing
|
SMD1010
|
COBSMD
|
SMD1010
|
|
Pixel configuration
|
1R1G1B
|
1R1G1B
|
1R1G1B
|
|
Gray scale
|
16bits per color
|
16bits per color
|
16bits per color
|
|
Best viewing distance
|
≥1m
|
≥1m
|
≥2m
|
|
Horizontal viewing angle
|
140º
|
140º
|
140º
|
|
Viewing angle
|
140º
|
140º
|
140º
|
|
Driving method
|
1/30 scan
|
1/32 scan
|
1/26 scan
|
|
Brightness
|
≥1000cd/m2
|
≥1000cd/m2
|
≥1500cd/m2
|
|
Frame frequency
|
50~60HZ
|
50~60HZ
|
50~60HZ
|
|
Refresh rate
|
≥3800HZ
|
≥3800HZ
|
≥3800HZ
|
|
IP grade
|
IP43
|
IP43
|
IP43
|
|
Cabinet size
|
400mm*300mm
|
480mm*480mm
|
400*300mm
|
|
Cabinet resolution
|
240*180 dots
|
256*256 dots
|
208*156 dots
|
|
Gross weight of cabinet
|
5kg
|
7.5kg
|
5kg
|
|
Max power consumption
|
130W/cabinet
|
200W/cabinet
|
120W/cabinet
|
|
Avg power consumption
|
42W/cabinet
|
65W/cabinet
|
40W/cabinet
|
|
Operating voltage
|
AC110V/220V±10%
|
|
Storage temperature
|
-40?-+65?
|
|
Working temperature
|
-20?-+55?
|
|
Storage working RH
|
10%—90%RH
|
|
MTBF
|
≥10,000 hours
|
|
Life span
|
≥100,000hours
|
|
Control method
|
Asynchronization/Synchronization
|
|
PC system
|
WinXP,Win2000,Vista, Win7 etc.
|
|
Control system
|
Nova/Linsn/Colorlight/DBstar etc
|
