CPU

Intel® Core™ i5-8250U (Kaby Lake-R)

OS

Linux / Windows 10 Home/IoT

RAM

4GB/8GB DDR3L

ROM

Standard eMMC5.0 32GB/64GB/128GB/256GB/512GB

SATA? M.2 2280 SSD 64GB/128GB/256GB/512GB Optional

SATA? 2.5 inch 5/ 7/ 9.5mm  Optional

WiFi

intel 3165 M.2 2230 / IEEE 802.11abgn/ac/d/e/i/h/w

Bluetooth

2.4G/5G Dual Mode Bluetooth 2.1, 2.1+EDR, 3.0, 4.0, 4.1,4.2 (BLE)

3G/4G

HUAWEI MU709s miniPCIE Optional

Ethernet

10M/100M/1000Mbps Intel i210-IT GBE?support Wake On Lan

I/O Ports

USB3.0 Type-A x4, HDMI 1.4A Type A x1, VGA DB15 x1, RJ45 x2, RS232 DB9 x3, 8bit DIO DB9 x1,

Line-in 3.5mm Phone Jack x1,Line-out 3.5mm Phone Jack x1,5.5/2.5mm DC Jack x1

SIM

Full Demension SIM x2

Antenna

Antenna1(WiFi+BTx1 ), Antenna2(3G/4G x2)

RTC/Watch dogs

real-time clock , time-switch, auto restart after crashed

Extensive

connector

miniPCIE x1, Extensive newtork port, USB, Serial port

Off & On Timer

Wake on Lan

For Bios / For RJ45

Adaptor

DC 12V/5A

Environment

-20~70? (With wide temperature rang SSD or eMMC)

With HDD operating temperature is 0~45?
