Fakra N Male Pastel Green Crimp Solder Connector for Car GPS Antenna RG316 RG174 Cable SHM.900.0009-1.N

Sihanming FAKRA connector is one of the auto parts. They are widely used in GPS, Remote control, car phone, car TV, hi-fi equipment, antennas, etc. It is mate with the same colors or connector and socket, and the structure is to be double-locked and fool-proofing for them

FAKRA Straight Female Connector Major characteristics:
   Double-locked, fool-proofing assembly with the color and the structure
   The connector is be protected by the cap .
   Easy to assembly
   Many difference between the connector and the cap.
 The product technical characteristics:
   Body: Brass, Ni-plated
   Socket: beryllium-copper, Gold-plated
   Pin contact: Brass
   Insulator: PTFE
   Fakra Female Crimp Solder Connector wholesale Crimp ferrule: brass, Ni-plated
   O-ring: beryllium-copper
   Shell: PA66+30%GF
 Technical characteristics
   Impedance: 50Ω
   Frequency Range: 4GHz
   Withstanding Voltage: 1000V(RMS)
   Contact resistance:
   Center contact: ≤ 20m
   Outer contact: ≤10m
   Insulation: ≥1,000MΩ
   GPS Car Antenna FAKRA Connector VSWR: DC - 2GHz<1.2
 Mechanical characteristics:
   Assembly: locked
   Durability: ≥ 500 cycles
   Temperature: - 40 - +85°C
