PP Drip Line Connectors Description
Features:
1. Made from virgin Polypropylene (PP), chemical corrosion resistant, ultraviolet ray resistant and aging resistant.
2. Unique wide or turbulent flow passageway ensures rated water flow and good clogging resistance.
3. Easy dismantlement and cleaning for detachable and washable drippers.
4. Stable flow rate at recommended pressure range: 1-1.5bar.
5. It can be connected to arrow dripper with Dn5mm PVC soft pipe, or can be directly installed on Dn12-32mmLDPE pipe with the hole punch.
6. It can be installed flexibly according to different crop distance, widely used in plants of many years’ growth, such as tress and grapes.
Farm drip irrigation Specifications:
|
S/N
|
ITEM NO.
|
NAME AND SPECIFICATION
|
Bag Qty
(Pc)
|
Quantity (Pcs/Ctn)
|
CARTON SIZE (CM)
|
G. weight per carton(kg)
|
|
1
|
AOD0170
|
Adjustable Dripper, 1/4" 0-70L/h 1bar
|
100
|
8800
|
54*35*28
|
15
|
|
2
|
AOD0170H
|
Adjustable Dripper, 1/4" 0-70L/h@1bar, stake 15cm length
|
100
|
1200
|
54*35*28
|
9
|
|
3
|
AS0180B
|
Adjustable Vortexing sprayer, 1/4" 0-80L/h
|
100
|
8800
|
54*35*28
|
15
|
|
4
|
AS0180H
|
Adjustable Vortexing sprayer with spike, 1/4" 0-80L/h
|
100
|
1200
|
54*35*28
|
9
|
Note?
For all above dripper with 1/4'' barb end could connected with 3*5mm micro pvc pipe, the hole puncher Dn3mm is needed for installation.
Dripper Technical Data
|
Click
|
Working Pressure (Bar) VS flow rate (L/H)
|
|
0.5bar
|
1.0bar
|
1.5bar
|
2.0bar
|
2.5bar
|
3.0bar
|
|
2
|
12.0
|
17.6
|
27.3
|
30.6
|
35.1
|
39.0
|
|
4
|
16.1
|
25.3
|
31.5
|
38.0
|
43.7
|
48.8
|
|
8
|
23.0
|
36.3
|
44.4
|
52.5
|
59.7
|
68.2
|
|
12
|
29.6
|
46.2
|
55.2
|
65.0
|
72.3
|
79.9
|
|
16
|
33.1
|
48.1
|
61.9
|
73.0
|
81.5
|
89.0
|
|
20
|
35.7
|
55.3
|
70.5
|
81.3
|
94.2
|
102.2
|
|
24
|
41.0
|
65.1
|
80.3
|
92.6
|
106.1
|
115.6
|
|
30
|
51.2
|
76.2
|
98.7
|
114.0
|
127.1
|
140.8
|
|
32
|
52.7
|
80.0
|
98.7
|
115.1
|
130.5
|
143.0
|
Custom drip irrigation system agriculture such as drip irrigation tape, PP drip tape valves and hole punch for customers from all over the world are our main business.
If you want to know more about Dripline or Drip Irrigation Accessories, please click here.
